SKYZONE SKY04X V2 OLED 5.8GHz 48CH Steadyview Receiver 1280X960 Display FPV Goggles Support DVR With Head Tracker Fan For RC Racing Drone
SKYZONE SKY04X V2 OLED 5.8GHz 48CH Steadyview Receiver 1280X960 OLED Display FPV Goggles Support DVR With Head Tracker Fan For RC Racing Drone
The SKY04X V2 is First skyzone goggle with focus adjustment,the 1280*960 high resolution screen have vivid color and high contrast ration,pilot can see more details in the racing.
With Steadyview receiver, the receiver merg two signal to one,avoid image tearing and rolling, make image more stable and clear in challenging condition.
The new designed optics have focus adjustment feature and 46 degree Field of view, gives pilots more immersive FPV experience.
The new OS with 10 languages to set select, pilot have no trouble with the menu system, with shuttle wheel and new user interface, pilot can set all the setting just by rolling the wheel without take off the goggles.
Description:
Brand:SKYZONE
Model:SKY04X V2
Item:5.8GHz 48CH Steadyview Receiver 1280X960 FPV Goggles
Screen:OLED
Resolution:1280X960
FOV (Diagonal):46??
AspectRatio:4:3/16:9
Focus:-6~+6 adjustable
Interpupillary distance(IPD):58-71mm
Receiver:5.8Ghz 48CH Steadyview Receiver
Language:10 Language
Power Supply:DC6.5-25.2V/USB5V
PowerConsumption:720mAat12V
DVR:H264,60fps, MOV6Mbps, SD Card support up to 128Gb
Head Tracker:3-axis Accelerometer, 3-axisgyroscope
Dimentions:185*75*67mm
Weight:267g
* SteadyView Receiver
SteadyView receiver merg two signal to one, make image more stable and clear in challenging condition.
With module bay, goggles have more capability to upgrade.
* Focus Adjustment.
The new Optics have large Field of View (46 degree). and the Optics have Focus adjustment feature (-6~+6), no need diopter any more.
* OELD Screen
The 1280*960 screen have high resolution and vivid color, high contrast ration, pilots can see more details.
* Advanced Screen Settings.
The aspect ration can is switchable, and 4 Preset screen setting and 3 customized setting for indoor, outdoor flight or different weather.
* Shuttle Wheel Control
No more confusing multi function button or 5 way Joy stick, with smooth and nature shuttle control, easy to navigate.
* New User Interface with 10 languages.
New UI with shuttle wheel, easy to navigate, 10 languages to choose for local user.
BAND/CHANNEL table:
| Band/CH | CH1 | CH2 | CH3 | CH4 | CH5 | CH6 | CH7 | CH8 |
| A | 5865M | 5845M | 5825M | 5805M | 5785M | 5765M | 5745M | 5725M |
| B | 5733M | 5752M | 5771M | 5790M | 5809M | 5828M | 5847M | 5866M |
| E | 5705M | 5685M | 5665M | 5645M | 5885M | 5905M | 5925M | 5945M |
| F | 5740M | 5760M | 5780M | 5800M | 5820M | 5840M | 5860M | 5880M |
| R | 5658M | 5695M | 5732M | 5769M | 5806M | 5843M | 5880M | 5917M |
| L | 5362M | 5399M | 5436M | 5473M | 5510M | 5547M | 5584M | 5621M |
| Sensitivity | -98dBm?I1dBm | |||||||
| Antenna Port | 2 X SMA-K,50ohm |
SKY04X FPV GOGGLE USER MANUAL:Click here
For any after-sales questions, please email to the official after-sales mailbox to get a quick response:john@skyzonehobbies.com
Package Included:
1x Goggles
1x Receiver Module
2x Faceplate (wide and narrow)
1x Sponge with velcr0
1x Zipper case
1x Power cable
1x Headtracker cable
2x 5.8GHz 2dD antennas
1x Video/Audio Cable
1x USB-C Cable
1x Uer Manual
